| Parameter | Specification |
| Pressure range | 900/1900kPa |
| Supply voltage | 2.1～3.6V |
| Output power | 0~10dBm（315/433Mhz/2.4Ghz） |
| Quiescent current (3V,25℃) | 0.5μA |
| Debug mode | ASK/FSK/GFSK |
| RF current (2.4GHz,0dBm) | 13mA |
| RF current (433/315MHz,5dBm) | 5.2~5.8mA |
| Temperature range | -40～125℃ |
| Package size | 6*5*1.9mm |
| Package | LGA 24PIN |
| Pressure accuracy (-40~125℃) | ±3kPa |
| Temperature accuracy (-20~70℃) | ±2℃ |
|
压力范围 |
900/1500Kpa |
|
工作电压 |
2.1～3.6V |
|
输出功率 |
0-10dBm（315/433Mhz/2.4Ghz） |
|
待机电流 (3V,25℃) |
0.5uA |
|
调试方式 |
ASK/FSK/GFSK |
|
RF电流 (2.4GHz,0dBm) |
13mA |
|
RF电流 (433/315MHz,5dBm) |
5.2~5.8mA |
|
工作温度 |
-40～125℃ |
|
封装尺寸 |
6*5*1.9mm |
|
封装形式 |
LGA 24PIN |
|
压力精度（-40~125℃） |
±3Kpa |
|
温度精度（-20~70℃） |
±2℃ |
