Position: > Home > Product > SMD Crystal
Crystal (5032)
Crystal (5032)
*High precision characteristics covering up to wide frequency range.
*Higher frequency stability and reliability.
*Excellent for reducing EMI effect.
*The best choice of Bluetooth, wireless communication set, DSC, PDA,mobile phone and USB interface card.
*RoHS Compliant / Pb Free.

深圳市晶光华电子有限公司推出尺寸5.0x3.2x0.9mm(SMD5032)贴片晶振,该晶振具有高精度、高稳定以及良好的可靠性,频率覆盖范围广,减少了电磁干扰效果,良好的谐振电阻,广泛应用于消费类电子及工控行业等,SMD5032系列晶振常规频率有8MHZ、12MHZ、18.08MHZ、20MHZ、24MHZ、25MHZ、27MHZ、30MHZ、32MHZ、48MHZ等

晶振特点:

5032无源晶振、4P贴片金属封装

频率范围宽、精度高

高频率稳定性和可靠性

降低EMI电磁干扰影响

无铅环保

晶振信息:


晶振尺寸:


*High precision characteristics covering up to wide frequency range.

*Higher frequency stability and reliability.

*Excellent for reducing EMI effect.

*The best choice of Bluetooth, wireless communication set, DSC, PDA,mobile phone and USB interface card.

*RoHS Compliant / Pb Free.

Image Types of Model Package size Frequency Voltage/load Frequency difference Operating temperature Sample Application PDF
Crystal(2016) Crystal(2016) S21 2.0x1.6x0.5mm 16-60MHZ 20PF or specif ±20PPM or specif -20℃~+70℃ or specif Browse
Crystal(2016) Crystal(2016) S21 2.0x1.6x0.5mm 16-60MHZ 20PF or specif ±20PPM or specif -20℃~+70℃ or specif Browse
Crystal (2520) Crystal (2520) 2520 2.5x2.0x0.45mm 12-54MHZ 20PF or specif ±20PPM or specif -40℃~+85℃ or specif Browse
Crystal (3225) Crystal (3225) S32 3.2x2.5x0.7mm 8-54MHZ 20PF or specif ±20PPM or specif -40℃~+85℃ or specif Browse
Crystal (49S) Crystal (49S) 49S 11.5x4.65x3.5mm 3.579545-64MHZ 20PF or specif ±20PPM or specif -20℃~+70℃ Browse
Crystal(MS7) Crystal(MS7) MS7 7.0x4.1x2.0mm 3.58-80MHZ 20PF or specif ±20PPM or specif -40℃~+85℃ or specif Browse
Crystal (49SSMD) Crystal (49SSMD) 49SSMD 11.4X4.8X3.8mm 3.58-80MHZ 20PF or specif ±20PPM or specif -40℃~+85℃ or specif Browse
Crystal (49SSMD) Crystal (49SSMD) 49SSMD 11.4X4.8X3.8mm 3.58-80MHZ 20PF or specif ±20PPM or specif -40℃~+85℃ or specif Browse
